2-1/2" Stainless Steel Lug Butterfly Valve
$
15.89
| Material | stainless steel |
| inlet connection size | 2-1/2 inch |
| inlet connection type | lug type |
| operation | manual (lever handle) |
The 2-1/2" lug butterfly valve is designed for on/off flow control of water, air, and oil. It has a lug-style body with threaded lugs, allowing it to be installed between two flanges in a pipeline using bolts. The valve has a stainless steel body, with stainless steel disc and stem. The seals are made of EPDM. The valve is manually operated with a quarter-turn lever handle.
Ships worldwide (International shipping fees apply)
Estimated delivery in 5–20 days
In stock
Note: This price applies to in-stock items available in limited quantities, typically offered as samples. For customized products or bulk orders, please request a quote via the shopping cart page or contact us by email.
Description
- The butterfly valve is used for on/off control or modulating the flow of water, air, and oil.
- The 2-1/2" lug butterfly valve is designed to be mounted between two ANSI-standard pipe flanges and is suitable for end-of-line use.
- The valve body is made of stainless steel, offering greater corrosion resistance compared to traditional brass or copper valves.
- The butterfly valve features a concentric design, in which the turning axis and axial alignment of the disc are both centered with the valve body, making it compact and cost-effective.
- The valve can be manually operated with a lever handle, allowing simple and quick quarter-turn operation to open or close the valve.
- The EPDM stem seals offer excellent resistance to water, steam, and mild chemicals, ensuring reliable sealing performance across a wide temperature range.
- The EPDM seat provides a tight shutoff and ensures sealing between the disc and the valve body.
- The stainless steel disc offers excellent corrosion resistance, durability, and strength.
- The maximum operating pressure is 232 psi (equivalent to PN16).
- The butterfly valve is designed for use with water, air, oil, and fuel. Typical applications include industrial/process piping, water treatment and irrigation.
Specifications
| Product Name | 2-1/2" stainless steel lug butterfly valve |
|---|---|
| valve type | butterfly valve |
| Material | stainless steel |
| port | 2-way |
| inlet connection size | 2-1/2 inch |
| inlet connection type | lug type |
| outlet connection size | 2-1/2 inch |
| outlet connection type | lug type |
| operation | manual (lever handle) |
| stem seals | EPDM |
| seat | EPDM |
| disc material | stainless steel |
| stem material | stainless steel |
| valve design | concentric |
| maximum pressure | 232 psi (PN16) |
| best suited media | water, air, oil |
| Item Type | lug butterfly valve |
| Brand Name | Hykins Basics |
Video
Compare with similar items
|
This item: 2-1/2" stainless steel lug butterfly valve
|
2" lever operated stainless steel lug butterfly valve
|
12" lever operated lug butterfly valve
|
3" ductile iron lug butterfly valve
|
|
| Customer Ratings | 3.9 (40) | 4.3 (62) | 4.7 (30) | 4.0 (74) |
| Price | $15.89 | $13.82 | $146.66 | $18.12 |
| valve type | butterfly valve | butterfly valve | butterfly valve | butterfly valve |
| port | 2-way | 2-way | 2-way | 2-way |
| port type | — | — | — | — |
| Material | stainless steel | stainless steel | cast iron | ductile iron |
| inlet connection size | 2-1/2 inch | 2 inch | 12 inch | 3 inch |
| inlet connection type | lug type | lug type | lug type | lug type |
| operation | manual (lever handle) | manual (lever handle) | manual (lever handle) | manual (lever handle) |
| stem seals | EPDM | EPDM | NBR | rubber |
| seat | EPDM | EPDM | NBR | rubber |
