2" lever operated stainless steel lug butterfly valve
$
13.82
In stock
| Material | stainless steel |
| inlet connection size | 2 inch |
| inlet connection type | lug type |
| operation | manual (hand lever) |
The 2" lug butterfly valve is designed for on/off flow control of water, air, and oil. It has a lug-style body with threaded lugs, allowing it to be installed between two flanges in a pipeline using bolts. The valve has an stainless steel body, with stainless steel disc and stem. The seals are made of EPDM. The valve is manually operated with a quarter-turn lever handle.
Description
- The butterfly valve is used for on/off control or modulating the flow of water, air, and oil.
- The 2" lug butterfly valve is designed to be mounted between two ANSI-standard pipe flanges and is suitable for end-of-line use.
- The valve body is made of stainless steel, offering greater corrosion resistance compared to traditional brass or copper valves.
- The butterfly valve features a concentric design, in which the turning axis and axial alignment of the disc are both centered with the valve body, making it compact and cost-effective.
- The valve can be manually operated with a lever handle, allowing simple and quick quarter-turn operation to open or close the valve.
- The EPDM stem seals offer excellent resistance to water, steam, and mild chemicals, ensuring reliable sealing performance across a wide temperature range.
- The EPDM seat provides a tight shutoff and ensures sealing between the disc and the valve body.
- The stainless steel disc offers excellent corrosion resistance, durability, and strength.
- The maximum operating pressure is 232 psi (equivalent to PN16).
- The butterfly valve is designed for use with water, air, oil, and fuel. Typical applications include industrial/process piping, water treatment and irrigation.
Specifications
| Product Name | 2" lever operated stainless steel lug butterfly valve |
|---|---|
| valve type | butterfly valve |
| Material | stainless steel |
| port | 2-way |
| inlet connection size | 2 inch |
| inlet connection type | lug type |
| outlet connection size | 2 inch |
| outlet connection type | lug type |
| operation | manual (hand lever) |
| stem seals | EPDM |
| seat | EPDM |
| disc material | stainless steel |
| stem material | stainless steel |
| valve design | concentric |
| maximum pressure | 232 psi (PN16) |
| best suited media | water, air, oil |
| Item Type | lug butterfly valve |
| Brand Name | Hykins Basics |
