3" Manual Stainless Steel Butterfly Valve With Handwheel
Estimated price:
$
57.55
(Final price may vary and will be confirmed via quote.)
| Material | stainless steel |
| inlet connection size | 3 inch |
| inlet connection type | flanged |
| operation | manual (handwheel) |
The 3" butterfly valve is designed for on/off flow control of water, air, and oil. It has flanges on both sides of its body, allowing it to be bolted directly to pipe flanges. The valve has a stainless steel body, with a stainless steel disc and stem. The seals are made of PTFE. The valve is manually operated with a quarter-turn handwheel.
Ships worldwide (International shipping fees apply)
Estimated delivery in 3–10 days
In stock
Customizable
Description
- The butterfly valve is used for on/off control or modulating the flow of water, air, and oil.
- The 3" flanged butterfly valve has flanges on both sides of its body, allowing it to be bolted directly to pipe flanges, which provides a more secure installation and more reliable sealing performance.
- The valve body is made of stainless steel, offering greater corrosion resistance compared to traditional brass or copper valves.
- The valve can be manually operated with low torque via a quarter-turn handwheel.
- The PTFE stem seals offer enhanced corrosion resistance and a long service life.
- The PTFE seat offers excellent sealing performance, even at low torque levels.
- The stainless steel disc offers excellent corrosion resistance, durability, and strength.
- The butterfly valve is designed for use with water, air, oil, and fuel. Typical applications include industrial/process piping, water treatment and irrigation.
Specifications
| Product Name | 3" manual stainless steel butterfly valve with handwheel |
|---|---|
| valve type | butterfly valve |
| Material | stainless steel |
| port | 2-way |
| inlet connection size | 3 inch |
| inlet connection type | flanged |
| outlet connection size | 3 inch |
| outlet connection type | flanged |
| operation | manual (handwheel) |
| stem seals | PTFE |
| seat | soft seated (PTFE) |
| disc material | stainless steel |
| stem material | stainless steel |
| best suited media | water, air, oil |
| Item Type | flanged butterfly valve |
| valve design | concentric |
| maximum pressure | 232 psi (PN16) |
| Reference | S-560731791392 |
| Brand | Hykins |
Video
Compare with similar items
|
This item: 3" manual stainless steel butterfly valve with handwheel
|
2" manual stainless steel flanged butterfly valve
|
2-1/2" stainless steel flanged butterfly valve
|
2-1/2" stainless steel lug butterfly valve
|
|
| Customer Ratings | 3.6 (7) | 4.3 (53) | 4.7 (72) | 3.9 (40) |
| Price | $57.55 | $47.52 | $53.32 | $15.89 |
| valve type | butterfly valve | butterfly valve | butterfly valve | butterfly valve |
| port | 2-way | 2-way | 2-way | 2-way |
| port type | — | — | — | — |
| Material | stainless steel | stainless steel | stainless steel | stainless steel |
| inlet connection size | 3 inch | 2 inch | 2-1/2 inch | 2-1/2 inch |
| inlet connection type | flanged | flanged | flanged | lug type |
| operation | manual (handwheel) | manual (handwheel) | manual (handwheel) | manual (lever handle) |
| stem seals | PTFE | EPDM | EPDM | EPDM |
| seat | soft seated (PTFE) | soft seated (EPDM) | EPDM | EPDM |
